* The original products may vary from the picture
Alstom Differential Protection relay CAG34AF71A
Visit the ALSTOM StoreSKU : alstom-CAG34AF71A
Mfr Part No. : CAG34AF71A
HSN Code : 8536
| GBCAG34AF71A |
| AC INSTANTANEOUS CIRCULATING CURRENT REL |
| Technical Specifications |
| Model No : - CAG34AF71A |
| TYPE - CAG34 |
| APPLICATION - DIFFERENTIAL |
| C.T. SECONDARY - 1 AMP CT. |
| CASE SIZE - 1D V 10T |
| CONTACTS (S/R OR H/R) - 2 N/O S/R |
| E/F OR U/V SETTING - NOT APPLICABLE |
| FLAG - YES |
| FREQUENCY - 50 HZ |
| MOUNTING - FLUSH |
| O/C OR O/V SETTING - 10 - 40% |
| STABLISING RESISTOR - 200 OHMS FOR 1A CT |
| External Resistor |
| Name Plate RFB9028-038 |
| Outline Diagram MFJ012 & FJ0297 |
| Wiring Diagram ADZ081-7-1 |
| Cut Out Dimension(in mm)-(H X W X D) - 222x150x203 |
Electro Mechanical Relay
