* The original products may vary from the picture
Alstom Tripping relays VAJHM23ZG0754BBA
Visit the GE VERNOVA - ALSTOM Store
SKU : Alstom-VAJHM23ZG0754BBA
Mfr Part No. : VAJHM23ZG0754BBA
HSN Code : 8536
| GBVAJHM23ZG0754BBA |
| 2 POLE HISPEED TRIP RELAY WITH COIL SUPE |
| Technical Specifications: |
| Relay model no - GBVAJHM23ZG0754BBA |
| Relay type - VAJHM23 |
| Aux. current or voltage - 110 - 125 V DC |
| Burden - HIGH |
| Case size - 1/2N HORZ. 20T |
| Contacts L.H Unit - 2 N/O 2 N/C |
| Contacts R.H Unit - 2 N/O 2 N/C |
| Total output contacts - 4 N/O 4 N/C H/R |
| Flag - Yes |
| Mounting - Flush |
| RESISTOR RSA-l OFF 47 OHMS <(>&<)> RSB-l OFF 200 Ohms |
| To be connected parallel per unit. |
| Name Plate - RFB9070 004 |
| Outline Diagram - FG0031 SHT. 3A |
| Wiring Diagram - 01VAJHM23ZG 001 |
| Cut Out Dimension(in mm)-(H X W X D) - 116x145x130 |
